DRV104PWPR Real Image DRV104PWPR Real Image
Same model may have multiple batches, images only for reference.
DRV104PWPR Real Image DRV104PWPR Real Image
DRV104PWPR Real Image DRV104PWPR Real Image
Same model may have multiple batches, images only for reference.

DRV104PWPR

Part No DRV104PWPR
Manufacturer Texas Instruments
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC HI-SIDE DRIVER PWM 14HTSSOP
Datasheet
DRV104PWPR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Switch Type Relay, Solenoid Driver
Number of Outputs 1
Voltage - Load 8 V to 32 V
Supply Voltage - Operating Not Required
Current - Output (Max) 1.2A
Input Type Non-Inverting
Features Internal PWM, Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature
Temperature Range - Operating -55°C to 125°C (TA)
Case / Package 14-HTSSOP
Win Source Part Number 014602-DRV104PWPR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Motor Drive & Control, Medical, HVAC
Ultra Librarian 3D Model Ultra Librarian DRV104PWPR CAD Model

Description

Product Overview

The DRV104PWPR is tailored for high-performance electronic systems requiring effective PWM control. As part of the esteemed DRV104 series, it delivers superior quality and functionality for intricate projects.

Features and Benefits

  • High-performance PWM modulation
  • Customizable operating frequency and duty cycle
  • Energy-efficient design to reduce power draw
  • Robust thermal performance for demanding conditions
  • Compact packaging for ease of incorporation

Applications

  • Precision Instrumentation
  • Energy-efficient Power Supplies
  • Industrial Control Systems
  • Smart Grid Technology

Additional Details

The DRV104PWPR is engineered to provide reliable performance for critical applications. It offers flexible customization to accommodate precise project requirements, making it a go-to choice for engineers prioritizing efficiency and reliability in system design.
