The INA138NA/250G4 is a precision current shunt monitor designed by Texas Instruments to offer industry-leading performance for accurate current measurement. This device is designed to work with a common-mode voltage range from -0.3V to 26V, making it highly versatile for various applications, including automotive, industrial, and power management systems.

Key Features

• High Accuracy: The INA138NA/250G4 provides a high level of accuracy with a typical error of less than 1%, ensuring precise current measurement for critical applications.
• Wide Common-Mode Range: With a common-mode voltage range from -0.3V to +26V, it can be used in systems with high-side current sensing and can operate at voltages beyond the supply rails.
• Low Quiescent Current: The device features a low quiescent current, which minimizes the impact on system power consumption and is ideal for battery-powered applications.
• Single Resistor Gain Set: The gain of the INA138NA/250G4 can be easily set with a single external resistor, providing flexibility and ease of use for designers.
• Small Form Factor: Available in the SOT23-5 package, the device occupies minimal board space, making it suitable for space-constrained applications.

Applications

• Power management systems
• Battery chargers
• Automotive systems
• Portable devices
• Energy management

Technical Specifications

The INA138NA/250G4 from Texas Instruments is a reliable and precise solution for current measurement in a wide array of applications. Its combination of accuracy, low power consumption, and small size makes it an excellent choice for designers looking to optimize their systems for performance and efficiency.
