INA170EA/2K5 Texas Instruments INA170EA/2K5 Real Image INA170EA/2K5 label picture INA170EA/2K5 real image 2
Same model may have multiple batches, images only for reference.
INA170EA/2K5 Texas Instruments INA170EA/2K5 Real Image INA170EA/2K5 label picture INA170EA/2K5 real image 2
INA170EA/2K5 Texas Instruments INA170EA/2K5 Real Image INA170EA/2K5 label picture INA170EA/2K5 real image 2
Same model may have multiple batches, images only for reference.

INA170EA/2K5

Part No INA170EA/2K5
Manufacturer Texas Instruments
Catalog PMIC - Current Regulation/Management
Description IC CURRENT MONITOR 2% 8VSSOP
Datasheet
INA170EA/2K5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Current Monitor
Sensing Method High-Side
Accuracy ±2%
Voltage - Input 2.7 V to 60 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 001820-INA170EA/2K5
Family Name INA170
Introduction Date November 01, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian INA170EA/2K5 CAD Model

Description

The INA170EA/2K5 from Texas Instruments is an innovative, high-performance current shunt monitor that is designed to offer a wide range of current sensing solutions for a variety of applications.

  • Measurement: High-side
  • Input Common-Mode Range: Wide
  • Gain Accuracy: 3%
  • Maximum Offset Voltage: 3mV
  • Operating Temperature Range: -40°C to 85°C
  • Package: Surface-mount SOIC
  • Compliance: RoHS compliant
  • Power Consumption: Minimal
