The INA240A4PWR is a high-precision current sense amplifier from Texas Instruments, designed to offer industry-leading performance for precision current measurement. With its wide input common-mode voltage range, low offset voltage, and small footprint, it is ideal for a wide range of applications including motor control, battery management, overcurrent protection, and power management systems.

Key Features:

• Wide Common-Mode Range: The INA240A4PWR operates over a common-mode voltage range from -0.2V to +80V, making it versatile for various applications where the supply voltages may vary.
• High Accuracy: It boasts a low offset voltage of ±80 µV (max) and gain error of ±0.1% (max), ensuring precise current measurement across the full operating temperature range (-40°C to +125°C).
• High Bandwidth: The device features a bandwidth of up to 400 kHz, which allows it to handle fast signal changes and to accurately track the current in high-speed systems.
• Quiescent Current: It consumes a low quiescent current of 310 µA (typical), which is beneficial for power-sensitive applications.
• Multiple Gain Options: The INA240 series offers multiple gain options to match the sensitivity requirements of different applications. The INA240A4PWR variant provides a gain of 400 V/V.

Applications:

• Automotive motor control
• Battery monitoring
• Overcurrent protection circuits
• Power management systems
• Portable instrumentation

The INA240A4PWR comes in a small TSSOP-16 package, which is ideal for space-constrained applications. Its robust design is complemented by features such as an extended temperature range and the ability to handle high voltage levels, making it a reliable choice for demanding environments. Whether it's for industrial, automotive, or consumer electronics, the INA240A4PWR from Texas Instruments is a high-performance solution for accurate current sensing.
