Product Overview: INA286AIDGKR by Texas Instruments

The INA286AIDGKR is a precision, bidirectional current-sense amplifier from Texas Instruments, designed to offer industry-leading performance for monitoring power supply and consumption in demanding applications. This integrated circuit is part of the INA286 series and comes in a compact 8-pin MSOP (DGK) package, making it suitable for space-constrained applications.

Key Features:

• High Accuracy: With its precision analog design, the INA286AIDGKR provides a high accuracy current sensing solution, ensuring reliable measurements for critical applications.
• Wide Common-Mode Range: The device operates over a wide common-mode voltage range of -0.3V to +80V, making it versatile for various systems.
• Low Offset Voltage: The low offset voltage of the amplifier minimizes error in current measurement, which is crucial for high-performance power monitoring.
• High Bandwidth: Offering a bandwidth of up to 500 kHz, the INA286AIDGKR is capable of capturing fast transient events, making it ideal for high-speed applications.
• Quiescent Current: It has a low quiescent current, which is beneficial for power-sensitive designs.

Applications:

The INA286AIDGKR is suited for a wide range of applications, including but not limited to:

• Power management in servers and telecom equipment
• Battery chargers and management systems
• Overcurrent protection circuits
• Automotive systems such as battery monitoring and motor control
• Industrial and test equipment for precision current monitoring

Quality and Reliability:

Texas Instruments is known for its commitment to quality, and the INA286AIDGKR is built to meet high standards of reliability and performance. This product is ROHS compliant and designed to withstand the rigors of industrial and automotive environments.

Support and Resources:

Designers can access a wealth of resources provided by Texas Instruments, including datasheets, application notes, and design tools, to facilitate the integration of the INA286AIDGKR into their projects. TI's customer support and community forums are also available to assist with any technical queries.
