LM1086ISX-3.3 Texas Instruments LM1086ISX-3.3 real image940 LM1086ISX-3.3 Real Image1 LM1086ISX-3.3 Real Image2
Same model may have multiple batches, images only for reference.
LM1086ISX-3.3 Texas Instruments LM1086ISX-3.3 real image940 LM1086ISX-3.3 Real Image1 LM1086ISX-3.3 Real Image2
LM1086ISX-3.3 Texas Instruments LM1086ISX-3.3 real image940 LM1086ISX-3.3 Real Image1 LM1086ISX-3.3 Real Image2
Same model may have multiple batches, images only for reference.

LM1086ISX-3.3

Part No LM1086ISX-3.3
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 3.3V 1.5A 4-Pin(3+Tab) DDPAK T/R / IC REG LDO 3.3V 1.5A DDPAK
Datasheet
LM1086ISX-3.3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 27V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.5V @ 1.5A
Output Current 1.5A
Operating Supply Current 5mA to 10mA
PSRR 72dB (120Hz)
Control Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.3V @ 1.5A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-3
Win Source Part Number 090978-LM1086ISX-3.3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LM1086
Introduction Date August 01, 1999
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian LM1086ISX-3.3 CAD Model

Description

The LM1086ISX-3.3 is a high-quality voltage regulator manufactured by the globally renowned company, Texas Instruments.

  • Output Voltage: Fixed 3.3V
  • Maximum Capacity: 1.5A
  • Dropout Rates: Extremely low, typically around 1.5V @ full load and lower @ lower load conditions
  • Thermal Performance: Exceptional
  • Features: Inbuilt thermal shutdown and current limit
  • Protection: Reverse battery protection system
  • Efficiency: High, reducing energy consumption and waste
