LM13700MX/NOPB Texas Instruments LM13700MX/NOPB Real Image LM13700MX/NOPB real image 2
Same model may have multiple batches, images only for reference.
LM13700MX/NOPB Texas Instruments LM13700MX/NOPB Real Image LM13700MX/NOPB real image 2
LM13700MX/NOPB Texas Instruments LM13700MX/NOPB Real Image LM13700MX/NOPB real image 2
Same model may have multiple batches, images only for reference.

LM13700MX/NOPB

Part No LM13700MX/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP TRANSCOND 2MHZ 16SOIC
Datasheet
LM13700MX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type Transconductance
Number of Circuits 2
Output Type Push-Pull
Slew Rate 50 V/μs
Gain Bandwidth Product (GBP) 2MHz
Current - Input Bias 1μA
Voltage - Input Offset 300μV
Operating Supply Current 2.6mA
Channel Output Current 650μA
Supply Voltage - Operating 10 V to 36 V, ±5 V to 18 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 018657-LM13700MX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Audio, Signal Processing, Clock & Timing
Ultra Librarian 3D Model Ultra Librarian LM13700MX/NOPB CAD Model

Description

The LM13700MX/NOPB is a high-performance, dual operational transconductance amplifier with linearizing diodes and buffers, manufactured by Texas Instruments.

  • Type: Dual operational transconductance amplifier
  • Features: Two independent operational amplifiers, each with differential inputs and a push-pull output
  • Transconductance: Large transconductance (gain)
  • Features: Linearizing diodes
  • Features: Buffers
  • Supply Voltages: ±5V to ±18V
  • Package: Compact, 16-pin SOIC package
  • Compliance: RoHS compliant
  • Free of: Lead, bromine and antimony
