The LM26400YSDX is a state-of-the-art dual output synchronous step-down DC/DC converter designed and manufactured by Texas Instruments. It is a highly integrated and efficient solution for applications requiring a compact, high-performance power supply. The device is capable of delivering up to 2A of continuous current per channel, making it suitable for powering core voltages, I/Os, and other system peripherals.

Key Features

• Dual Channel: Two independent 2A outputs with separate enable pins allow for versatile power management schemes.
• Wide Input Voltage Range: Operates from a 2.7V to 5.5V input, accommodating a variety of power sources including single-cell Li-ion batteries and 3.3V or 5V system rails.
• High Efficiency: Integrated synchronous MOSFETs enhance efficiency, reducing the need for external components and minimizing power loss.
• Adjustable Switching Frequency: Users can set the switching frequency from 500kHz to 4MHz, optimizing efficiency and component size.
• Power Save Mode: At light loads, the device automatically enters power save mode, reducing quiescent current and maintaining high efficiency over the entire load range.
• Thermal Protection: Built-in thermal shutdown and over-temperature protection safeguard the device from damage due to overheating.

Applications

The LM26400YSDX is ideal for a broad range of applications, including but not limited to:

• Portable and battery-powered devices
• Networking and telecommunications equipment
• Industrial and automotive systems
• Point-of-load power supplies

Package and Availability

This converter is available in a compact 14-pin WSON package, making it ideal for space-constrained applications. Its small footprint, combined with the high level of integration, reduces the overall solution size and bill of materials cost. For pricing, samples, and ordering information, please visit the Texas Instruments website or contact an authorized distributor.

Note: It is important to consult the LM26400YSDX datasheet for detailed specifications, recommended layout, pin configurations, and application notes to ensure optimal performance in your design.
