LM2941S Real Image LM2941S Real Image1 LM2941S Real Image2 LM2941S Real Image3 LM2941S Real Image4 LM2941S Real Image5
Same model may have multiple batches, images only for reference.
LM2941S Real Image LM2941S Real Image1 LM2941S Real Image2 LM2941S Real Image3 LM2941S Real Image4 LM2941S Real Image5
LM2941S Real Image LM2941S Real Image1 LM2941S Real Image2 LM2941S Real Image3 LM2941S Real Image4 LM2941S Real Image5
Same model may have multiple batches, images only for reference.

LM2941S

Part No LM2941S
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 1A DDPAK
Datasheet
LM2941S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 26V
Nominal Output Voltage (Min/Fixed) 5V
Maximum Output Voltage 20V
Dropout Voltage-Max 1V @ 1A
Output Current 1A
Operating Supply Current 10mA to 15mA
Control Features Enable
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 5 V to 20 V
Voltage - Dropout (Typical) 0.5V @ 1A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-5
Win Source Part Number 090906-LM2941S
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Automotive, Industrial
Ultra Librarian 3D Model Ultra Librarian LM2941S CAD Model

Description

The LM2941S from Texas Instruments is a high-quality, advanced voltage regulator that is designed to cater to a wide range of applications.

  • Adjustable Output: Down to 1V
  • Input Voltage Range: 4.5V to 26V
  • Maximum Output Current: 1A
