LM3535TMX/NOPB Texas Instruments
Same model may have multiple batches, images only for reference.

LM3535TMX/NOPB

Part No LM3535TMX/NOPB
Manufacturer Texas Instruments
Catalog PMIC - LED Drivers
Description IC LED DRIVER RGLTR DIM 20USMD
Datasheet
LM3535TMX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type DC DC Regulator
Topology Switched Capacitor (Charge Pump)
Internal Switch(s) Yes
Number of Outputs 8
Operating Input Voltage(Min) 2.7V
Maximum Supply Voltage 5.5V
Output Voltage 2 V to 4 V
Channel Output Current 25mA
Frequency 1.33MHz
Dimming PWM
Applications Backlight
Temperature Range - Operating -30°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 20-uSMD
Win Source Part Number 137860-LM3535TMX/NOPB
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM3535TMX/NOPB CAD Model

Description

The LM3535TMX/NOPB is a high-performance, adaptive LED backlight driver and ambient light sensor interface developed by Texas Instruments.

  • Brightness Mapping: Logarithmic and linear LED brightness mapping.
  • Ambient Light Sensor Interface: Integrated ambient light sensor interface.
  • Converter: High-efficiency boost converter.
  • Input Voltage Range: 2.7V to 5.5V
  • Dynamic Headroom Control: Adjusts the LED supply voltage dynamically.
  • LED Current Sinks: Nine programmable LED current sinks.
  • PWM Generator: Programmable PWM generator.
  • Over-Voltage Protection: Over-voltage protection circuit.
  • Thermal Shutdown Circuit: Thermal shutdown circuit.
