LM3565TLX/NOPB Texas Instruments – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

LM3565TLX/NOPB

Part No LM3565TLX/NOPB
Manufacturer Texas Instruments
Catalog PMIC - LED Drivers
Description IC LED DRVR RGLTR PWM 9 16DSBGA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 1
Voltage - Supply (Min) 2.5V
Voltage - Supply (Max) 5.5V
Voltage - Output 5.5V ~ 8.5V
Current - Output / Channel 930mA (Flash)
Frequency 4MHz
Dimming PWM
Applications Camera Flash
Temperature Range - Operating -30°C ~ 85°C (TA)
Mounting Type Surface Mount
Case / Package 16-WFBGA, DSBGA
Supplier Device Package 16-DSBGA (2.5x2.12)
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1565935-LM3565TLX/NOPB
