LM5009MM Real Image LM5009MM real image LM5009MM real image1574 LM5009MM Real Image1 LM5009MM Real Image2 LM5009MM Real Image3 LM5009MM Real Image4
Same model may have multiple batches, images only for reference.
LM5009MM Real Image LM5009MM real image LM5009MM real image1574 LM5009MM Real Image1 LM5009MM Real Image2 LM5009MM Real Image3 LM5009MM Real Image4
LM5009MM Real Image LM5009MM real image LM5009MM real image1574 LM5009MM Real Image1 LM5009MM Real Image2 LM5009MM Real Image3 LM5009MM Real Image4
Same model may have multiple batches, images only for reference.

LM5009MM

Part No LM5009MM
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJ 0.15A 8VSSOP
Datasheet
LM5009MM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 9.5V
Maximum Input Voltage 95V
Nominal Output Voltage (Min/Fixed) 2.5V
Maximum Output Voltage 85V
Output Current 150mA
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 85319-LM5009MM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Automotive
Ultra Librarian 3D Model Ultra Librarian LM5009MM CAD Model

Description

The LM5009MM is a highly advanced, high-voltage switching regulator that is specifically designed to provide efficient, high-performance service for a wide range of applications manufactured by Texas Instruments.

  • Type: Step-down regulator
  • Input Voltage Range: 9V to 100V
  • Control Scheme: Constant on-time (COT)
  • Package: 10-pin VSSOP
  • Operating Temperature: -40°C to 125°C
  • Integrated Features: High-side N-Channel MOSFET, startup regulator
