LM5009MMX Real Image LM5009MMX real image LM5009MMX Real Image
Same model may have multiple batches, images only for reference.
LM5009MMX Real Image LM5009MMX real image LM5009MMX Real Image
LM5009MMX Real Image LM5009MMX real image LM5009MMX Real Image
Same model may have multiple batches, images only for reference.

LM5009MMX

Part No LM5009MMX
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJ 0.15A 8VSSOP
Datasheet
LM5009MMX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 9.5V
Maximum Input Voltage 95V
Nominal Output Voltage (Min/Fixed) 2.5V
Maximum Output Voltage 85V
Output Current 150mA
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 090104-LM5009MMX
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LM5009MMX CAD Model

Description

The LM5009MMX is a sophisticated, highly versatile, and efficient power management product from Texas Instruments, a renowned global semiconductor company that designs and manufactures analog ICs and embedded processors.

  • Type: Step-down switching regulator
  • Input Voltage Range: 6V to 95V
  • Switch: 100V N-Channel buck switch
  • Switching Frequency: Adjustable up to 500kHz
  • Output Voltage: Adjustable from 2.5V to 90V
  • Output Voltage Accuracy: ±2%
  • Package: 8-pin MSOP-PowerPAD
  • Junction Temperature Range: -40°C to 125°C
