Introducing the LM5022QDGSRQ1 from Texas Instruments

The LM5022QDGSRQ1 is a high-performance, automotive-grade, low-emission, step-up PWM voltage-mode controller designed by Texas Instruments to meet the rigorous demands of the automotive industry. This advanced power management IC is engineered to provide efficient and reliable control for boost, flyback, and SEPIC power supply configurations.

Key Features

• Voltage Input Range: The LM5022QDGSRQ1 operates over a wide input voltage range from 3V to 42V, making it suitable for a variety of automotive applications that require consistent performance under fluctuating power conditions.
• Switching Frequency: This device offers a programmable switching frequency ranging from 100 kHz to 1 MHz, allowing designers to optimize their power supply for efficiency or component size.
• Integrated MOSFET Driver: It includes a high-side gate driver for an external N-channel MOSFET, which provides robust and efficient switching.
• Thermal Shutdown: Enhanced safety features, such as thermal shutdown, protect the device and the system from excessive temperature conditions.
• Current Limit Protection: The LM5022QDGSRQ1 is equipped with cycle-by-cycle current limit protection, which contributes to safe operation during overload conditions.
• Automotive-Qualified: As a Q1 device, it meets the AEC-Q100 Grade 1 standard, ensuring reliable operation in automotive environments with a temperature range of -40°C to 125°C.

Applications

The LM5022QDGSRQ1 is particularly well-suited for automotive applications where a reliable and efficient power supply is critical. Its robustness and versatility make it an ideal choice for:

• Automotive infotainment systems
• Power supplies for car audio systems
• Automotive lighting systems
• Telematics and navigation systems
• Advanced driver-assistance systems (ADAS)

With its advanced features and automotive-grade reliability, the LM5022QDGSRQ1 from Texas Instruments stands out as a superior choice for designers looking to develop high-performance power supply solutions in the automotive sector. Its ease of integration, coupled with a comprehensive set of protection features, ensures that systems powered by the LM5022QDGSRQ1 will deliver consistent performance and longevity.
