LM5576MHX Texas Instruments LM5576MHX Real Image LM5576MHX real image1641 LM5576MHX Real Image LM5576MHX real image 2 LM5576MHX label picture
Same model may have multiple batches, images only for reference.
LM5576MHX Texas Instruments LM5576MHX Real Image LM5576MHX real image1641 LM5576MHX Real Image LM5576MHX real image 2 LM5576MHX label picture
LM5576MHX Texas Instruments LM5576MHX Real Image LM5576MHX real image1641 LM5576MHX Real Image LM5576MHX real image 2 LM5576MHX label picture
Same model may have multiple batches, images only for reference.

LM5576MHX

Part No LM5576MHX
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description Conv DC-DC 6V to 75V Inv/Step Down Single-Out 1.225V to 70V 3A 20-Pin HTSSOP EP T/R / IC REG BUCK ADJ 3A 20TSSOP
Datasheet
LM5576MHX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 6V
Maximum Input Voltage 75V
Nominal Output Voltage (Min/Fixed) 1.225V
Maximum Output Voltage 70V
Output Current 3A
Frequency - Switching 50kHz to 500kHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 20-HTSSOP
Win Source Part Number 087979-LM5576MHX
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LM5576
Introduction Date March 01, 2007
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian LM5576MHX CAD Model

Description

The LM5576MHX from Texas Instruments is a highly efficient, versatile power management device designed for a wide range of applications.

  • Device Type: Step-down switching regulator
  • Input Voltage Range: 6V to 75V
  • Output Voltage: Adjustable output voltage
  • Efficiency: High efficiency
  • Operating Frequency: Fixed frequency PWM controller that operates at a frequency of 500 kHz
  • Protection Features: Thermal shutdown, undervoltage lockout, cycle-by-cycle current limit, frequency foldback
  • Package: Compact 20-pin HTSSOP PowerPAD package
