LM8272MM/NOPB Real Image LM8272MM/NOPB real image1695 LM8272MM/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM8272MM/NOPB Real Image LM8272MM/NOPB real image1695 LM8272MM/NOPB Real Image
LM8272MM/NOPB Real Image LM8272MM/NOPB real image1695 LM8272MM/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM8272MM/NOPB

Part No LM8272MM/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 15MHZ RRO 8VSSOP
Datasheet
LM8272MM/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 15 V/μs
Gain Bandwidth Product (GBP) 15MHz
-3db Bandwidth 12.5MHz
Current - Input Bias 2μA
Voltage - Input Offset 700μV
Operating Supply Current 1.9mA
Channel Output Current 65mA
Supply Voltage - Operating 2.5 V to 24 V, ±1.25 V to 12 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 019465-LM8272MM/NOPB
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Signal Processing, Sensing & Instrumentation
Ultra Librarian 3D Model Ultra Librarian LM8272MM/NOPB CAD Model

Description

The is a high-performance, dual operational amplifier from Texas Instruments, a reputable semiconductor technology company.

  • Supply Voltage Range: 2.7V to 5.5V
  • Slew Rate: 20V/µs
  • Input Bias Current: Low (1pA)
  • Input Offset Voltage: 3mV
  • Package: 10-VSSOP
  • Applications: Driving ADC inputs, buffering DAC outputs, audio processing
  • Environmental Compliance: RoHS and Green standards
  • Protection: ESD and thermal shutdown
