Product Overview: LMK04806BISQX/NOPB

The LMK04806BISQX/NOPB is a highly integrated, low-noise clock jitter cleaner and precision clock distributor from Texas Instruments. Designed to meet the stringent requirements of complex systems such as telecommunications, data communications, medical imaging, and industrial applications, this device offers an optimal solution for synchronizing clocks across several peripherals and platforms.

Key Features

• Low Noise Jitter Cleaning: The LMK04806BISQX/NOPB features advanced PLLatinum™ technology to reduce system jitter, ensuring high-performance clocking for noise-sensitive applications.
• Dual PLLs: Equipped with two PLLs, it can generate multiple high-quality clock signals, providing flexibility for various system requirements.
• Frequency Flexibility: This device supports a wide range of input frequencies, from 8 kHz to 1.5 GHz, allowing it to cater to a diverse set of applications.
• Programmable Outputs: It includes up to 14 programmable outputs, each capable of generating different clock frequencies, which can be tuned to meet specific design needs.
• Integrated EEPROM: With an on-chip EEPROM, users can store custom configurations, enabling fast and easy device initialization during power-up.

Applications

• Data Converters
• Wireless Infrastructure
• Networking Equipment
• Test and Measurement Systems
• Medical Imaging Devices

Quality and Reliability

The LMK04806BISQX/NOPB is manufactured by Texas Instruments, a leader in semiconductor solutions, ensuring high standards of quality and reliability. The device is available in a compact, 48-pin WQFN package, making it suitable for space-constrained applications.

Environmental and Safety Compliance

As indicated by the "NOPB" (No Lead or Pb) in its part number, the LMK04806BISQX/NOPB is lead-free and RoHS compliant, aligning with environmental directives for electronic components.

With its robust feature set and adherence to environmental standards, the LMK04806BISQX/NOPB from Texas Instruments is an excellent choice for designers looking to enhance their system's clocking architecture while maintaining signal integrity and minimizing noise.
