PTN78000AAH

Part No PTN78000AAH
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description REG SW -15 TO -3.3V 1.5A HORZ TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Standard Package 56
Category Power Supplies - Board Mount
Family DC DC Converters
Series PTN78000A
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 7V
Voltage - Input (Max) 28.7V
Voltage - Output 1 -15 ~ -3 V
Current - Output (Max) 1.5A
Applications ITE (Commercial)
Mounting Style Through Hole
Package 5-DIP Module
Size / Dimension 0.75" L x 0.50" W x 0.34" H (19.1mm x 12.7mm x 8.6mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 84%
Power (Watts) - Max 9W
Catalog PTN78000A
Win Source Part Number 085392-PTN78000AAH
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PTN78000AAH CAD Model

Description

The PTN78000AAH is a high-performance, integrated module from Texas Instruments, a global semiconductor design and manufacturing company.

  • Type: High-efficiency, step-down integrated switch regulators (ISR)
  • Output Voltages: Adjustable from 2.5V to 12.6V
  • Output Current: Up to 1.5A
  • Input Voltage Range: From 14V to 40V
  • Efficiency: Up to 96%
  • Control: On/off inhibit control and output voltage adjustability.
  • Package: Space-efficient, 7-pin, through-hole mount, thermally-enhanced package.
  • Protection: Over-temperature and over-current protection features.
  • Compliance: RoHS directive
