SN65C3232EDR Real Image SN65C3232EDR Real Image1 SN65C3232EDR Real Image2 SN65C3232EDR Real Image3 SN65C3232EDR Real Image4 SN65C3232EDR Real Image5
Same model may have multiple batches, images only for reference.
SN65C3232EDR Real Image SN65C3232EDR Real Image1 SN65C3232EDR Real Image2 SN65C3232EDR Real Image3 SN65C3232EDR Real Image4 SN65C3232EDR Real Image5
SN65C3232EDR Real Image SN65C3232EDR Real Image1 SN65C3232EDR Real Image2 SN65C3232EDR Real Image3 SN65C3232EDR Real Image4 SN65C3232EDR Real Image5
Same model may have multiple batches, images only for reference.

SN65C3232EDR

Part No SN65C3232EDR
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC LINE DRVR/RCVR RS232 16-SOIC
Datasheet
SN65C3232EDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 1Mbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 082121-SN65C3232EDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN65C3232EDR CAD Model

Description

The SN65C3232EDR is a high-quality, high-performance product designed and manufactured by Texas Instruments, a recognized leader in the semiconductor industry.

  • Type: Dual driver/receiver
  • Features: Capacitive voltage generator to supply TIA/EIA-232-F voltage levels from a single 5-V supply
  • Data Signaling Rate: Up to 250 kbit/s
  • Driver Output Slew Rate: Maximum of 30-V/µs
  • Operational Temperature Range: -40 to 85 Celsius
  • Standard Compliance: TIA/EIA-232-F
  • Feature: Automatic power-down function
  • ESD Protection: ±15-kV ESD protected pin (HBM)
  • Package: SOIC (D)
  • Compliance: Lead-free / RoHS compliant
