SN65HVD22DR Real Image SN65HVD22DR real image5716
SN65HVD22DR Real Image SN65HVD22DR real image5716
Same model may have multiple batches, images only for reference.

SN65HVD22DR

Part No SN65HVD22DR
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC TXRX RS485 EXT MODE 8-SOIC / Single Transmitter/Receiver RS-485 8-Pin SOIC T/R
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 130mV
Data Rate 500kbps
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 029530-SN65HVD22DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name SN65HVD22
Introduction Date February 01, 2007
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian SN65HVD22DR CAD Model

Description

The SN65HVD22DR is a high-performance, robust product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Operation: Differential line transceiver
  • Applications: RS-485 and RS-422
  • Common-Mode Range: Wide
  • Temperature Range: -40°C to 85°C
  • Supply Voltage: 5V
  • Signaling Rate: Up to 5 Mbps
  • Driver and Receiver Outputs: 3-state, supports up to 32 bus load devices
  • Power Mode: Low-power standby mode
  • Input/Output: Differential
  • ESD Protection: Advanced
  • Package: 8-pin SOIC (Small Outline Integrated Circuit)
  • Compliance: RoHS compliant
