SN74AHC132DR Texas Instruments SN74AHC132DR Real Image
Same model may have multiple batches, images only for reference.
SN74AHC132DR Texas Instruments SN74AHC132DR Real Image
SN74AHC132DR Texas Instruments SN74AHC132DR Real Image
Same model may have multiple batches, images only for reference.

SN74AHC132DR

Part No SN74AHC132DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 4CH 2-INP 14-SOIC
Datasheet
SN74AHC132DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Features Schmitt Trigger
Supply Voltage - Operating 2 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 8mA, 8mA
Logic Level - Low 0.9 V to 1.65 V
Logic Level - High 2.2 V to 3.85 V
Max Propagation Delay @ V, Max CL 9.7ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 006534-SN74AHC132DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN74AHC132DR CAD Model

Description

The SN74AHC132DR is a high-performance, integrated circuit device from Texas Instruments, an industry leader in semiconductor manufacturing.

  • Device type: quadruple positive-NAND gate with Schmitt-trigger inputs
  • Voltage Range: 2V to 5.5V
  • Inputs: Schmitt-trigger inputs provide hysteresis
  • Power Consumption: Low
  • Operating Temperature Range: -40°C to 85°C
  • Package: small-outline
  • Compatibility: TTL outputs
  • tpd: maximum 13 ns
