SN74AHCT273PWR Real Image SN74AHCT273PWR real image5887
Same model may have multiple batches, images only for reference.
SN74AHCT273PWR Real Image SN74AHCT273PWR real image5887
SN74AHCT273PWR Real Image SN74AHCT273PWR real image5887
Same model may have multiple batches, images only for reference.

SN74AHCT273PWR

Part No SN74AHCT273PWR
Manufacturer Texas Instruments
Catalog Logic - Flip Flops
Description IC D-TYPE POS TRG SNGL 20TSSOP
Datasheet
SN74AHCT273PWR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Master Reset
Type D-Type
Output Type Non-Inverted
Number of Elements 1
Number of Bits per Element 8
Max Frequency 75MHz
Max Propagation Delay @ V, Max CL 9.2ns @ 5V, 50pF
Trigger Type Positive Edge
Current - Output High, Low 8mA, 8mA
Supply Voltage - Operating 4.5 V to 5.5 V
Current - Quiescent 4μA
Input Capacitance 2.5pF
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Dimension 20-TSSOP (0.173", 4.40mm Width)
Win Source Part Number 065204-SN74AHCT273PWR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN74AHCT273PWR CAD Model

Description

The SN74AHCT245DBR is a high-performance integrated circuit (IC) manufactured by the globally renowned company, Texas Instruments.

  • Description: Octal Bus Transceiver specifically designed with 3-state outputs.
  • Operating Voltage: operates on a voltage range of 4.5 V to 5.5 V.
  • Operating Temperature Range: characterized for operation from -40°C to 85°C.
  • Compliance: RoHS compliant and lead-free.
  • Package: available in a SSOP (DB) package.
