SN74AUP1G08DCKR Real Image SN74AUP1G08DCKR real image5902 SN74AUP1G08DCKR Real Image1 SN74AUP1G08DCKR Real Image2
Same model may have multiple batches, images only for reference.
SN74AUP1G08DCKR Real Image SN74AUP1G08DCKR real image5902 SN74AUP1G08DCKR Real Image1 SN74AUP1G08DCKR Real Image2
SN74AUP1G08DCKR Real Image SN74AUP1G08DCKR real image5902 SN74AUP1G08DCKR Real Image1 SN74AUP1G08DCKR Real Image2
Same model may have multiple batches, images only for reference.

SN74AUP1G08DCKR

Part No SN74AUP1G08DCKR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE AND 1CH 2-INP SC-70-5
Datasheet
SN74AUP1G08DCKR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type AND Gate
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 0.8 V to 3.6 V
Current - Quiescent (Max) 0.5μA
Current - Output High, Low 4mA, 4mA
Logic Level - Low 0.7 V to 0.9 V
Logic Level - High 1.6 V to 2 V
Max Propagation Delay @ V, Max CL 6.2ns @ 3.3V, 30pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 029887-SN74AUP1G08DCKR
Family Name SN74AUP1G08
Introduction Date May 01, 2005
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN74AUP1G08DCKR CAD Model

Description

The SN74AUP1G08DCKR is a high-performance, advanced 2-input positive-AND gate produced by Texas Instruments, a renowned global semiconductor company.

  • Technology: CMOS technology.
  • Voltage Range: 0.8V to 3.6V.
  • Inputs/Outputs: Two inputs and one output.
  • Propagation Delay Time: 4.2 ns.
  • Temperature Range: -40°C to 85°C.
  • Package: Compact SC-70 package.
  • Compliance: RoHS compliant.
  • Static Power Consumption: Maximum ICC of just 0.9 µA @ 25°C.
