SN74F04DR Real Image SN74F04DR real image SN74F04DR label picture
Same model may have multiple batches, images only for reference.
SN74F04DR Real Image SN74F04DR real image SN74F04DR label picture
SN74F04DR Real Image SN74F04DR real image SN74F04DR label picture
Same model may have multiple batches, images only for reference.

SN74F04DR

Part No SN74F04DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC HEX INVERTER 14-SOIC
Datasheet
SN74F04DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Supply Voltage - Operating 4.5 V to 5.5 V
Current - Output High, Low 1mA, 20mA
Logic Level - Low 0.8V
Logic Level - High 2V
Max Propagation Delay @ V, Max CL 5ns @ 5V, 50pF
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 006709-SN74F04DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN74F04DR CAD Model

Description

The SN74F04DR is a high-performance hex inverter chip developed by Texas Instruments, a renowned American technology company that designs and manufactures semiconductors and various integrated circuits.

  • Pins: 14-pin
  • Inverters: Six independent inverters
  • Supply Voltage Range: 4.5V to 5.5V
  • Maximum Propagation Delay Time: 3.8ns
  • Circuitry: Advanced Schottky TTL circuitry
  • Noise Immunity: High
  • Power Consumption: Low
  • Package: Small and thin SOIC package
  • Input Impedance: High
  • Output Impedance: Low
  • Compliance: RoHS compliant
