SN74HC00PWRG4 Real Image SN74HC00PWRG4 real image
Same model may have multiple batches, images only for reference.
SN74HC00PWRG4 Real Image SN74HC00PWRG4 real image
SN74HC00PWRG4 Real Image SN74HC00PWRG4 real image
Same model may have multiple batches, images only for reference.

SN74HC00PWRG4

Part No SN74HC00PWRG4
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 4CH 2-INP 14-TSSOP
Datasheet
SN74HC00PWRG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.5 V to 1.8 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 15ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-TSSOP
Dimension 14-TSSOP (0.173", 4.40mm Width)
Win Source Part Number 065486-SN74HC00PWRG4
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN74HC00PWRG4 CAD Model

Description

The SN74HC00PWRG4 by Texas Instruments is a high-performing, advanced integrated circuit device that is part of the SN74HC00 series.

  • Series: SN74HC00
  • Type: Quadruple 2-input NAND gate
  • Operating Voltage Range: 2V to 6V
  • Output Drive: High-current outputs, can drive up to 10 Low Power Schottky loads
  • Compatibility: Functional compatibility with 5V logic devices
  • Package: TSSOP (Thin Shrink Small Outline Package) with 14 pins
  • Operating Temperature Range: -40°C to 85°C
  • Compliance: RoHS compliant
