SN74HC86DR Texas Instruments SN74HC86DR Real Image SN74HC86DR label picture
Same model may have multiple batches, images only for reference.
SN74HC86DR Texas Instruments SN74HC86DR Real Image SN74HC86DR label picture
SN74HC86DR Texas Instruments SN74HC86DR Real Image SN74HC86DR label picture
Same model may have multiple batches, images only for reference.

SN74HC86DR

Part No SN74HC86DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE XOR 4CH 2-INP 14-SOIC
Datasheet
SN74HC86DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type XOR (Exclusive OR)
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.5 V to 1.8 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 17ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 030147-SN74HC86DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN74HC86DR CAD Model

Description

The SN74HC86DR from Texas Instruments is a high-performance, advanced chip that exemplifies the company's commitment to innovation and quality.

  • Supply Voltages: from 2V to 6V
  • Technology: advanced CMOS technology
  • Operating Temperature Range: from -40°C to 85°C
  • Package: SOIC-14
