The SN74LVC2G14DCKT is a high-performance, dual Schmitt-trigger inverter IC from Texas Instruments designed for use in a wide array of applications that require signal conditioning with hysteresis. This integrated circuit is part of the LVC family, which signifies its low-voltage CMOS technology, making it suitable for operation with a power supply range of 1.65V to 5.5V. This broad voltage range ensures compatibility with various logic levels, making it ideal for interfacing with both low-voltage and standard 5V systems.

Key Features

• Logic Type: Inverter with Schmitt Trigger Input
• Number of Circuits: 2
• Supply Voltage Range: 1.65V to 5.5V
• Output Current: ±8mA
• Propagation Delay Time: 3.4ns at 3.3V, 8.2ns at 1.8V
• Operating Temperature Range: -40°C to 125°C
• Mounting Type: Surface Mount
• Package / Case: SC-70 (SOT-363)
• RoHS: Compliant

Applications

The SN74LVC2G14DCKT is versatile in its application due to its dual inverter design with Schmitt-trigger inputs. These features make it particularly useful in signal processing tasks such as:

• Square wave generation
• Wave shaping and noise filtering
• Logic level translation
• Glitch removal on digital signals
• Line drivers for long cable runs

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the SN74LVC2G14DCKT is no exception. This device is manufactured to the highest standards, ensuring stable performance across its operational temperature range and longevity in various environmental conditions. Whether used in industrial, commercial, or consumer electronics, the SN74LVC2G14DCKT is a reliable choice for designers looking to incorporate a robust signal conditioning solution.
