Texas Instruments SN74LVTH16374DGGR Product Description

The SN74LVTH16374DGGR from Texas Instruments is a high-performance, 16-bit edge-triggered D-type flip-flop. It is part of the LVT and LVTH series of the 3.3-V ABT wide bus family, designed with a low voltage (3.3V) supply for high speed operation, while maintaining the low power consumption of CMOS circuitry.

It features a bus-hold circuitry that eliminates the need for external pullup or pulldown resistors on unconnected inputs, making it highly efficient. The device is also equipped with a latch-up performance exceeding 500 mA, providing a high degree of reliability.

The SN74LVTH16374DGGR has a wide operating temperature range of -40°C to 85°C, providing flexibility for a variety of applications. It features two types of flip-flops, one with a direct clear (CLR) and preset (PRE) and the other with a complementary output from the D-type flip-flop.

Notably, the SN74LVTH16374DGGR is designed with an 8-Bit to 9-Bit parity bus switch with a parity generator/checker and flag output options. The parity generator/checker can generate/verify parity for data words from 8 bits to 64 bits.

This IC is designed in a 48-pin TSSOP (DGGR) package, which is compact and suitable for space-constrained applications. It also features a 'bus-hold data' input circuitry that eliminates the need for external pull-up resistors to hold unused or floating data inputs.

The SN74LVTH16374DGGR is RoHS compliant and lead-free, making it an environmentally friendly choice. Its applications include memory address drivers, clock drivers, and bus-oriented receivers and transmitters in systems that range from computers to controllers.

With its high-speed performance, low power consumption, and high reliability, the SN74LVTH16374DGGR from Texas Instruments is a superior choice for your digital logic needs.
