The TLV1117-50IDCYR is a low-dropout linear voltage regulator from Texas Instruments, designed to provide a fixed 5V output with an input voltage range from 2.7V to 10V. This regulator is capable of delivering up to 800mA of output current, making it suitable for a wide range of applications, including powering microcontrollers, analog circuits, and other digital ICs that require a stable 5V supply.

Key Features

• Output Voltage: Fixed 5V with a precision of 2% at 25°C, ensuring reliable performance for sensitive electronic components.
• Output Current: Capable of supplying up to 800mA, which is ample for many low-power devices and systems.
• Low Dropout Voltage: Offers a dropout voltage typically around 1.2V at 800mA load, allowing for efficient operation even with input voltages close to the output voltage.
• Thermal Protection: Integrated thermal shutdown protection prevents damage from overheating, enhancing the longevity of the device.
• Current Limiting: Built-in output current limiting protects the regulator and the load from damage due to overcurrent conditions.
• Stable with Low-ESR Capacitors: Stable with ceramic capacitors, which can be important for space-constrained applications.
• Package: Available in a small SOT-223 package, the TLV1117-50IDCYR is ideal for space-sensitive applications.

Applications

The TLV1117-50IDCYR is versatile and can be used in various applications such as:

• Consumer Electronics
• Portable Devices
• Power Supplies for Microcontrollers and Digital Systems
• Post-Regulation for Switching Supplies

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the TLV1117-50IDCYR is no exception. It is designed to meet the rigorous demands of the industry, with a robust design that ensures reliable performance over a wide range of temperatures and conditions. Whether you are designing a new product or looking for a reliable power solution, the TLV1117-50IDCYR offers the performance and dependability that you can trust.
