Overview of Texas Instruments TLV1117IDRJR

The TLV1117IDRJR from Texas Instruments is a reliable low-dropout voltage regulator designed for applications that require a regulated power supply. This voltage regulator is capable of delivering a continuous output current of up to 800mA, making it suitable for a wide range of electronic devices and systems.

Key Features

• Output Voltage: The device offers a fixed output voltage option, providing a stable and precise voltage supply to your circuit.
• Low Dropout: Its low dropout voltage ensures efficient operation even when the input voltage is close to the output voltage, which is essential for battery-powered devices.
• Thermal and Overcurrent Protection: The TLV1117IDRJR includes built-in thermal shutdown and current limit features, safeguarding your application from potential damage due to overheating or excessive current draw.
• Stable with Low-ESR Capacitors: This voltage regulator is stable with low equivalent series resistance (ESR) capacitors, which reduces the size and cost of the capacitors needed for the application.

Applications

The versatile nature of the TLV1117IDRJR makes it an ideal choice for a variety of applications, including:

• Consumer Electronics
• Portable and Battery-Powered Devices
• Microprocessor Power Supplies
• Post-Regulation for Switching Supplies

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the TLV1117IDRJR is no exception. It is designed to meet the rigorous standards required by industrial and commercial applications, ensuring long-term reliability and performance.

Package and Availability

The TLV1117IDRJR is available in a compact SOT-223 package, making it easy to integrate into your design with minimal footprint. Its surface-mount design is suitable for automated assembly processes, facilitating efficient manufacturing and scalability for high-volume production.

In summary, the Texas Instruments TLV1117IDRJR is a robust and efficient solution for your voltage regulation needs, combining performance, protection features, and ease of use in a small package form factor.
