The TLV70030DCKR is a highly efficient, low-dropout (LDO) voltage regulator from Texas Instruments, designed to deliver a stable and precise voltage supply. This compact component is a perfect fit for a wide range of applications, including portable electronics, where power efficiency and space constraints are critical considerations.

Key Features

• Output Voltage: The TLV70030DCKR provides a fixed output voltage of 3.0V, which is ideal for powering 3V logic in microcontrollers, sensors, and other digital systems.
• High Accuracy: This regulator maintains a high level of accuracy, with a typical output voltage tolerance of ±2%, ensuring reliable performance for sensitive electronic circuits.
• Low Dropout: With a low dropout voltage of just 250 mV at 200 mA, the TLV70030DCKR is highly efficient, making it suitable for battery-powered applications where maximizing battery life is essential.
• Current Capacity: It can deliver up to 200 mA of continuous output current, making it capable of powering a variety of low-power devices.
• Thermal Protection: The device includes built-in thermal shutdown protection, which safeguards the regulator and the system against excessive temperature rises.
• Overcurrent Protection: Overcurrent protection is also integrated, which helps prevent damage to the regulator during fault conditions.

Package and Availability

The TLV70030DCKR is offered in a compact 5-pin SC-70 package, which is highly valued for its small footprint. This package is designed for surface-mount technology (SMT), allowing for efficient assembly and space-saving on printed circuit boards (PCBs).

Applications

This voltage regulator is suitable for a diverse range of applications, including but not limited to:

• Handheld devices
• Portable media players
• Wireless peripherals
• Healthcare monitors
• Smart meters

With its stable output, low power consumption, and compact design, the TLV70030DCKR from Texas Instruments is an excellent choice for designers looking to optimize their power management solutions.
