Overview of Texas Instruments TPS2113PWR

The Texas Instruments TPS2113PWR is a versatile power multiplexer that allows seamless transition between two power sources, making it an ideal solution for dual-supply systems. This component is part of the AutoSwitch™ family of power multiplexers, which are designed to automatically switch between two power sources without interruption to the load.

Key Features

• Wide Voltage Range: The TPS2113PWR operates over a broad voltage range from 2.8V to 5.5V, making it suitable for various applications, including battery-powered devices.
• Current Limiting: It features built-in current limiting, which protects the device from overcurrent conditions, enhancing system reliability.
• Low On-Resistance: The low on-resistance (rON) of the internal FET switch ensures high efficiency and minimal voltage drop across the switch, preserving energy in battery-operated systems.
• Break-Before-Make Switching: The TPS2113PWR employs break-before-make switching to prevent cross-conduction and shorting between the supplies during transitions.
• Power Good Outputs: It includes two open-drain power-good outputs, one for each input source, providing a straightforward way to monitor the status of the power supplies.

Applications

Due to its dual-supply switching capability and robust feature set, the TPS2113PWR is well-suited for a variety of applications, including:

• Redundant power supplies in servers and networking equipment
• Portable devices with dual battery systems
• Uninterruptible power supplies (UPS)
• Power source switching for industrial and instrumentation systems

Package and Quality

The TPS2113PWR comes in a compact TSSOP-8 (Thin Shrink Small Outline Package) that is space-efficient, making it a great choice for size-constrained applications. Texas Instruments is known for its commitment to quality, and this product is no exception, meeting high standards for performance and reliability.

Conclusion

With its combination of features, such as automatic switching, current limiting, and low on-resistance, the Texas Instruments TPS2113PWR is a powerful solution for managing dual power supplies in a wide range of electronic devices. Its compact package and robust design ensure it can meet the needs of demanding applications while providing a dependable power management solution.
