Introducing the Texas Instruments TPS2511DGNR

The TPS2511DGNR is a cutting-edge USB dedicated charging port (DCP) controller and current-limiting power switch from the esteemed manufacturer Texas Instruments (TI). This highly integrated device is designed to facilitate the charging of a wide array of portable electronics, such as smartphones, tablets, and other USB-powered gadgets. Its intelligent design allows it to automatically detect the type of device connected and provide the appropriate charging signature, ensuring compatibility with a multitude of charging protocols.

Key Features

• Auto-Detect Functionality: The TPS2511DGNR comes with an auto-detect feature that identifies USB standard downstream ports (SDP), charging downstream ports (CDP), and dedicated charging ports (DCP).
• Integrated Power Switch: It includes an integrated 2.5A, 70mΩ power switch with over-current and thermal protection, ensuring safe operation and protection for both the charging device and the power source.
• Flexibility: This device supports a wide range of input voltages from 4.5V to 5.5V, making it versatile for use in various USB-powered applications.
• Charge Rate Optimization: The TPS2511DGNR optimizes the charge rate for USB devices by automatically adjusting the output current.
• Compact Package: Housed in an 8-pin MSOP PowerPAD™ package, it is designed for space-constrained applications.

Applications

The TPS2511DGNR is ideal for a variety of applications where USB charging is required. It is particularly suited for:

• Wall chargers
• Car chargers
• Power banks
• USB hubs and docking stations
• Portable media players

Technical Specifications

With its advanced features, the TPS2511DGNR ensures reliable and efficient charging. The device is compliant with USB Battery Charging Specification 1.2 and has a programmable current limit up to 2.5A. Its thermal shutdown feature adds an extra layer of safety, and it has a wide operating temperature range from -40°C to 85°C.

In summary, the TPS2511DGNR from Texas Instruments is an intelligent and versatile solution for USB charging applications, providing safety, compatibility, and efficiency in a compact form factor.
