The TPS259571DSGR is a sophisticated circuit protection device engineered by Texas Instruments (TI), a leader in semiconductor solutions. This high-efficiency, eFuse Power Switch offers a compact and reliable solution for systems requiring overcurrent protection and hot-swap functionality. Its applications span across a wide range of industries, including enterprise systems, automotive, telecommunications, and industrial controls.

Key Features

• Adjustable Overcurrent Protection: The device provides programmable overcurrent protection to safeguard against excessive current that could potentially damage the system.
• Integrated FET: With an integrated 28mΩ N-channel FET, the TPS259571DSGR ensures low on-resistance, enabling efficient power distribution and minimal power loss.
• Operating Voltage Range: It operates over a wide input voltage range from 2.7V to 18V, making it suitable for a variety of low to mid-range voltage applications.
• Fast Overcurrent Response: The device features a fast response time to overcurrent conditions, which helps to prevent damage to sensitive components by quickly disconnecting the load.
• Thermal Shutdown: An integrated thermal shutdown function protects the device and the system from overheating.
• Under-Voltage Lockout (UVLO): The UVLO feature ensures that the device operates only when the input voltage is within the specified range, enhancing system reliability.

Product Benefits

The TPS259571DSGR from Texas Instruments is designed to enhance system robustness and reliability. Its precise current limiting and fast trip times protect downstream components from damage due to overcurrent and short-circuit events. Additionally, the device's small form factor, available in a 3.00 mm × 3.00 mm 10-pin VSON package, allows for space-saving on PCBs, making it ideal for compact designs.

Applications

Due to its versatile features, the TPS259571DSGR is an excellent choice for a variety of applications, including:

• Servers and storage systems
• Automotive infotainment and telematics
• Networking equipment such as switches and routers
• Industrial control systems
• Portable and battery-powered electronics

With the TPS259571DSGR, designers can confidently integrate overcurrent protection into their systems, ensuring both safety and efficiency.
