Product Overview: TPS3711DDCR by Texas Instruments

The TPS3711DDCR is a state-of-the-art voltage detector designed by Texas Instruments, renowned for its precision and reliability. This compact device is engineered to monitor over-voltage and under-voltage conditions, ensuring that your electronic systems operate within their specified voltage ranges, thereby safeguarding them from potential damage.

Key Features

• Wide Voltage Range: The TPS3711DDCR can monitor threshold voltages from 0.4 V to 5.5 V, making it highly versatile for various applications.
• High Accuracy: With a precision threshold accuracy of 0.5%, this device offers reliable monitoring, ensuring that voltage deviations are detected promptly.
• Low Quiescent Current: The device features a remarkably low quiescent current of 1.8 µA (typical), which is essential for power-sensitive applications.
• Adjustable Delay Time: It comes with an adjustable delay time feature that prevents false triggering due to transient voltage fluctuations.
• Manual Reset Input: A manual reset input allows for an external trigger to reset the system, offering additional control to the user.

Applications

The TPS3711DDCR is ideal for a wide array of applications, including:

• Industrial systems
• Consumer electronics
• Portable/battery-powered devices
• Automotive electronics
• Computing platforms

Package and Availability

Encased in a 6-pin SOT-23 package, the TPS3711DDCR is designed for compactness and ease of integration into various circuit designs. Its small footprint allows for efficient use of PCB space, making it an excellent choice for space-constrained applications.

As a product of Texas Instruments, a leader in semiconductor solutions, the TPS3711DDCR is backed by rigorous quality testing and support. It is available for order through Texas Instruments' official distributors, ensuring that you receive authentic and high-quality components for your electronic projects.
