Product Overview: TPS61016DGS - Texas Instruments

The TPS61016DGS is a high-frequency, synchronous boost converter with an integrated 2-A switch, designed by Texas Instruments to provide efficient power management for a wide range of applications. It operates with an input voltage range from 0.9V to 6.5V, making it ideal for products powered by single-cell batteries or standard power supplies.

This versatile DC-DC converter is capable of delivering a stable and adjustable output voltage up to 14V, which can be set using external resistors. The high switching frequency of up to 3.4MHz allows the use of small, low-profile inductors and ceramic capacitors, thereby reducing the overall solution footprint on the PCB.

The TPS61016DGS offers several features that ensure the protection and longevity of your application. It includes under-voltage lockout (UVLO), over-temperature protection, and a true load disconnect feature which isolates the load from the power source when the device is disabled. Furthermore, its Power Save Mode enhances efficiency at light loads, resulting in extended battery life for portable applications.

This component is available in a compact 8-pin MSOP PowerPAD™ package, designed for thermal enhancement. The small form factor makes the TPS61016DGS a perfect choice for space-constrained applications such as handheld devices, wearable electronics, and IoT devices.

Key features of the TPS61016DGS include:

• Adjustable output voltage up to 14V
• Up to 3.4MHz switching frequency for small inductor and capacitor sizes
• Integrated 2-A, 0.2-Ohm power switch
• Power Save Mode for improved efficiency at light loads
• True load disconnect feature
• Protection features: UVLO, over-temperature, and over-current protection
• Small 8-pin MSOP PowerPAD™ package for enhanced thermal performance

With its robust feature set and compact design, the TPS61016DGS from Texas Instruments is an excellent choice for designers looking to optimize power efficiency and save space in their next project.
