Overview of TPS61175PWPRG4

The TPS61175PWPRG4 is a high-voltage boost converter from Texas Instruments designed to accommodate a wide input voltage range and deliver a stable output voltage. This component is a part of the TPS61175 series, which is known for its efficiency and reliability in managing power supply requirements for various applications.

Key Features

• Input Voltage Range: The TPS61175PWPRG4 operates with an input voltage range from 3V to 18V, making it versatile for both low and high input voltage applications.
• Adjustable Output Voltage: Users can adjust the output voltage up to 38V via an external resistor divider, catering to a wide range of power needs.
• High Efficiency: With an integrated 1.2A, 20V power MOSFET, the converter achieves high efficiency, which is crucial for battery-powered devices.
• Switching Frequency: The device features a fixed 600kHz switching frequency, which allows the use of small external components, reducing the overall solution size.
• Thermal Shutdown: It includes thermal shutdown protection that safeguards the device from overheating, enhancing system reliability.
• Overvoltage Protection: The TPS61175PWPRG4 is equipped with overvoltage protection, preventing damage to downstream components in the event of irregular voltage spikes.

Applications

The TPS61175PWPRG4 is suitable for a broad range of applications, including but not limited to:

• Power supplies for LCD TVs and monitors
• LED backlighting for monitors and laptops
• Portable power banks
• Automotive infotainment and navigation systems
• Industrial and medical equipment

Package and Availability

This device is available in a 16-pin HTSSOP (PWP) package, providing a compact solution for space-constrained applications. The 'R' suffix in the part number indicates that the product is offered in a reel package, which is typically used for automated manufacturing processes.

Manufactured by Texas Instruments, a leader in semiconductor solutions, the TPS61175PWPRG4 is a testament to the company's commitment to providing high-quality and energy-efficient power management devices.
