Product Overview: TPS62240DRVT from Texas Instruments

The TPS62240DRVT is a high-efficiency synchronous step-down DC/DC converter brought to you by Texas Instruments, a leader in semiconductor solutions. Designed for battery-powered and low-power applications, this device is capable of providing up to 300mA output current while maintaining a high efficiency across the entire load range.

Key Features

• High Efficiency: The TPS62240DRVT boasts an impressive efficiency rate, which is achieved through its 2.25MHz fixed switching frequency, allowing the use of small inductors and capacitors to minimize the solution size and the power loss.
• Wide Input Voltage Range: This versatile converter operates over a wide input voltage range from 2V to 6V, making it suitable for various applications, including those powered by lithium-ion batteries or regulated 5V and 3.3V power rails.
• Adjustable Output Voltage: The output voltage can be programmed from 0.7V to 6V, allowing the device to power a wide range of low-power ICs.
• Power Save Mode: It includes a power save mode that reduces quiescent current and maintains high efficiency during light load operation, extending battery life in portable devices.
• Low Ripple: The TPS62240DRVT provides low output voltage ripple and excellent transient response, ensuring stable operation for sensitive RF and analog circuitry.

Applications

The TPS62240DRVT is ideal for a multitude of applications, particularly where power efficiency and space constraints are critical. Some common applications include:

• Portable and battery-powered equipment
• Wireless handsets and WLAN devices
• GPS navigation systems
• Point-of-load conversions from a 3.3V or 5V rail
• Personal multimedia devices

Package and Quality

Encased in a small 2x2mm SON package, the TPS62240DRVT is designed for space-constrained applications. The device also features over-temperature and over-current protection, enhancing system reliability. Texas Instruments is committed to maintaining high-quality standards, and this product is no exception, ensuring robust performance for your electronic designs.

With its comprehensive set of features, the TPS62240DRVT from Texas Instruments stands as a highly efficient, flexible, and reliable solution for your power management needs.
