The TPS73201DCQR is a high-performance, low-dropout linear regulator (LDO) brought to you by Texas Instruments, a leader in semiconductor solutions. This regulator is specifically designed to deliver a stable and precise voltage supply, making it an ideal component for sensitive electronics that require a clean power source.

Key Features

• Stable Output: With an output voltage range that can be programmed from 1.25V to 5.5V using external resistors, the TPS73201DCQR offers versatile performance for a variety of applications.
• High Accuracy: The device boasts an impressive accuracy level, with a typical output voltage tolerance of ±2%, ensuring reliable operation for critical applications.
• Low Dropout: The low dropout voltage (typically 250mV at 250mA) allows for efficient operation even when the supply voltage is close to the output voltage, reducing power loss and improving efficiency.
• Thermal Protection: Integrated thermal shutdown protection safeguards the device and your application from damage due to overheating.
• Current Limiting: Built-in current limiting protects the device and the load from excessive currents that may occur during fault conditions.

Applications

The TPS73201DCQR is suitable for a wide range of applications, including:

• Battery-powered devices
• Portable and handheld equipment
• Microcontroller power supplies
• Post-regulation for switching power supplies
• Analog and digital circuits that require precise voltage control

Product Specifications

Parameter Value Output Voltage Range 1.25V to 5.5V Dropout Voltage 250mV @ 250mA Output Current Up to 250mA Accuracy ±2% (typical) Package SOT-223-6

With its robust feature set and Texas Instruments' reputation for quality, the TPS73201DCQR is an excellent choice for designers seeking a reliable LDO voltage regulator for their next project.
