TPS73633DBVRG4

Part No TPS73633DBVRG4
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 0.4A SOT23-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.2V @ 400mA
Output Current 400mA
Operating Supply Current 550μA to 1mA
PSRR 58dB to 37dB (100Hz to 10kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 1112985-TPS73633DBVRG4
Popularity Medium
Supply and Demand Status Sufficient
Application Field Used in Industrial, Portable Devices, Power Management
Ultra Librarian 3D Model Ultra Librarian TPS73633DBVRG4 CAD Model

Description

Product Overview: TPS73633DBVRG4 from Texas Instruments

The TPS73633DBVRG4 is a high-value, low-dropout (LDO) voltage regulator from the reputable semiconductor manufacturer Texas Instruments (TI). This efficient and reliable regulator is designed to cater to a wide range of applications, including portable and battery-powered devices, where maintaining a stable voltage is critical for optimal performance.

Key Features

  • Output Voltage: The TPS73633DBVRG4 provides a fixed output voltage of 3.3V, which is essential for powering a variety of standard digital and analog circuits.
  • High Accuracy: It boasts an impressive accuracy of 1%, ensuring that the output remains precise and consistent, which is crucial for sensitive electronics.
  • Low Dropout: The LDO has a very low dropout voltage, which means it can continue to provide a regulated output even when the supply voltage is very close to the output voltage, maximizing battery life.
  • Current Capacity: This device can deliver up to 400mA of continuous output current, making it suitable for a broad array of medium-power applications.
  • Thermal Protection: It includes built-in thermal shutdown protection that helps prevent damage from overheating, enhancing the product's reliability and lifespan.
  • Low Quiescent Current: The TPS73633DBVRG4 features a low quiescent current, which is beneficial for battery-powered devices as it helps to minimize power consumption when the device is in standby mode.

Package and Quality

The regulator is housed in a compact SOT-23-5 package, which is ideal for space-constrained applications. The small footprint of the package allows for efficient use of board space without sacrificing performance. TI's commitment to quality ensures that the TPS73633DBVRG4 meets the stringent requirements of industrial standards, providing a robust solution for your power regulation needs.

Applications

With its versatile features, the TPS73633DBVRG4 is well-suited for a diverse range of applications, including but not limited to:

  • Portable Electronics
  • Wireless Communication Devices
  • Power Management for DSPs and Microcontrollers
  • Consumer Electronics
  • Medical Devices

In conclusion, the TPS73633DBVRG4 from Texas Instruments is a high-performance, reliable LDO voltage regulator that offers a balance of accuracy, efficiency, and thermal protection, making it an excellent choice for designers looking to enhance their power management solutions.
