Product Overview: TPS76901SDBVTEP from Texas Instruments

The TPS76901SDBVTEP, manufactured by Texas Instruments (TI), is a highly reliable, low-dropout (LDO) voltage regulator specifically designed to meet the stringent requirements of high-performance electronic systems. This device is part of TI's Enhanced Product (EP) lineup, which signifies that it has been optimized for military and space applications where extended temperature ranges and long-term availability are crucial.

With a fixed output voltage of 1.0V and capable of delivering up to 100mA of continuous current, the TPS76901SDBVTEP is ideal for powering sensitive analog and digital circuits that require a stable and clean power supply. Its low dropout voltage allows it to operate efficiently, even when the input-to-output voltage differential is minimal, ensuring that the system remains functional even under conditions of low battery voltage.

The device features a low quiescent current of just 17μA in the active mode and 1μA in shutdown mode, which significantly enhances the power efficiency and prolongs battery life in portable applications. Moreover, the TPS76901SDBVTEP includes built-in over-current and over-temperature protection, safeguarding the device and the system it powers against adverse conditions.

For ease of integration into various circuit designs, the TPS76901SDBVTEP comes in a compact SOT-23-5 package. Its small footprint and low profile make it suitable for space-constrained applications, while its robust design ensures reliable operation even in harsh environments.

Key features of the TPS76901SDBVTEP include:

• Fixed output voltage: 1.0V
• Output current: 100mA
• Low dropout voltage
• Low quiescent current: 17μA (active), 1μA (shutdown)
• Over-current and over-temperature protection
• Enhanced Product (EP) designation for military and space applications
• Operating temperature range: -55°C to +125°C
• Compact SOT-23-5 package

Overall, the TPS76901SDBVTEP LDO voltage regulator is a testament to Texas Instruments' commitment to providing high-quality, reliable power management solutions suitable for the most demanding applications. Whether used in aerospace, defense, or precision electronics, this device delivers the performance and durability needed for mission-critical systems.
