The TPS793285YEQR is a high-performance, low-dropout (LDO) linear voltage regulator designed and manufactured by Texas Instruments. This precision device is tailored to meet the stringent power requirements of portable and space-constrained electronics, providing a stable and reliable power supply for a variety of applications.

Key Features

• High Accuracy: The TPS793285YEQR boasts an impressive output voltage accuracy, ensuring that connected devices receive a consistent voltage supply.
• Low Dropout: With a low dropout voltage, this LDO regulator maintains its output regulation with minimal input-to-output voltage difference, making it highly efficient in battery-operated devices.
• Fast Transient Response: The device is designed to respond quickly to changes in load conditions, which is crucial for maintaining voltage stability in dynamic systems.
• Low Quiescent Current: It features a low quiescent current, which minimizes power consumption when the device is in idle mode, thus extending battery life in portable applications.
• Thermal Shutdown and Overcurrent Protection: The TPS793285YEQR is equipped with built-in safety features that protect the device and the system from damage due to excessive heat or current.

Applications

The versatile nature of the TPS793285YEQR makes it suitable for a wide range of applications, including:

• Mobile phones and PDAs
• Portable media players
• Wireless LAN cards
• Handheld instrumentation
• GPS devices

Product Specifications

The TPS793285YEQR operates with an input voltage range from 2.7V to 6.0V and delivers a fixed output voltage of 2.85V, which is precisely regulated to meet the needs of sensitive electronic components. It is available in a compact 5-pin SOT-23 package, making it ideal for space-constrained applications.

Ordering Information

For those looking to integrate the TPS793285YEQR into their designs, the product is available for ordering under the part number TPS793285YEQR. It is supplied in tape and reel packaging, facilitating easy assembly during the manufacturing process.

Conclusion

The TPS793285YEQR from Texas Instruments represents a blend of performance, efficiency, and reliability, making it a top choice for designers and engineers who require a high-quality power management solution.
