The TPS92513DGQT is a highly efficient, adaptive LED driver IC designed and manufactured by Texas Instruments. This sophisticated device is engineered to deliver precise current regulation for LED lighting systems, making it an ideal solution for a wide range of applications, including architectural lighting, commercial lighting, and automotive systems.

Key Features

• Integrated MOSFET: The TPS92513DGQT includes an integrated 2.5A, 40V power MOSFET, which simplifies the design and reduces external component count.
• Wide Input Voltage Range: This LED driver operates from a wide input voltage range of 4.5V to 42V, accommodating various power supplies and ensuring consistent performance across different voltage levels.
• Flexible Dimming Options: The device supports both analog and PWM dimming control methods, enabling precise brightness control to suit user preferences and application requirements.
• Thermal Protection: With built-in thermal shutdown protection, the TPS92513DGQT ensures reliable operation by preventing damage due to overheating.

Performance and Efficiency

The TPS92513DGQT is designed with efficiency in mind. Its constant current control ensures uniform brightness across LED strings, while its adaptive on-time control with selectable frequency dithering minimizes EMI emissions. The device also features an adjustable soft start, which limits inrush current and provides a smooth power-up sequence for the LEDs.

Package and Reliability

Encased in a compact 10-pin MSOP PowerPAD™ package, the TPS92513DGQT is not only space-efficient but also offers enhanced thermal performance. The robust design of this LED driver guarantees high reliability and a long operational lifespan, which is crucial for reducing maintenance costs and ensuring continuous lighting operation.

Applications

With its versatile features and reliable performance, the TPS92513DGQT is suitable for a variety of LED lighting applications. It is particularly adept at driving high-brightness LEDs in general illumination products, automotive lighting, and industrial lighting fixtures, where consistent light quality and energy efficiency are of paramount importance.
