The Texas Instruments TXB0104QPWRQ1 is a versatile, 4-bit non-inverting level shifter designed for bidirectional voltage-level translation in multi-voltage systems. This high-performance integrated circuit (IC) is particularly well-suited for applications that require a seamless interface between different logic voltage domains.

Key Features

• Bi-Directional Translation: The TXB0104QPWRQ1 is capable of translating signals bidirectionally between two different voltage nodes, making it ideal for data transfer between low-voltage and high-voltage circuits.
• Auto-Direction Sensing: The device automatically senses and adjusts the direction of the data flow without the need for a direction control signal, simplifying the design and reducing pin count.
• Wide Voltage Range: It supports a wide range of input voltages from 1.2V to 3.6V on the VCCA side and 1.65V to 5.5V on the VCCB side, offering compatibility with a variety of logic levels.
• Low Power Consumption: The TXB0104QPWRQ1 is designed for low power operation, which helps to conserve energy in battery-powered devices.
• Robust ESD Protection: The device includes 15 kV ESD protection on all pins, providing robust protection against electrostatic discharge events.

Applications

The TXB0104QPWRQ1 is suitable for a broad range of applications that require voltage level translation, such as:

• Mobile Devices
• Computing Devices
• Consumer Electronics
• Telecommunication Infrastructure
• Automotive Systems

Package and Quality

The device is offered in a compact QFN-16 package, which allows for a reduced footprint on printed circuit boards. Texas Instruments' commitment to quality ensures that the TXB0104QPWRQ1 meets strict industry standards for performance and reliability, making it a trusted choice for designers and engineers.
