The Texas Instruments TXS0104ERGYR is a 4-bit bidirectional voltage-level translator designed for open-drain and push-pull applications. This state-of-the-art device is a vital component for systems where interfacing between different voltage levels is essential, making it an indispensable tool for designers working on multi-voltage digital system integration.

Key Features

• Voltage Level Translation: Capable of translating signals between two distinct voltage nodes ranging from 1.65V to 3.6V on the A side (VCCA) and 2.3V to 5.5V on the B side (VCCB), the TXS0104ERGYR ensures seamless communication between devices operating at different voltage levels.
• Bidirectional Data Flow: This translator supports bidirectional data flow without the need for a direction control signal, simplifying the design and saving valuable GPIOs for other functions.
• Low Power Consumption: With its low power consumption, the TXS0104ERGYR is an excellent choice for battery-operated and power-sensitive applications, ensuring efficient operation without compromising performance.
• Auto-Direction Sensing: The device automatically senses the direction of data flow and switches accordingly, providing a plug-and-play experience for engineers.
• Robust ESD Protection: Integrated electrostatic discharge (ESD) protection circuitry shields the device from the harmful effects of static electricity, ensuring reliability and longevity in harsh environments.

Applications

The TXS0104ERGYR is highly versatile and can be used in various applications, including but not limited to:

• Mobile Phones
• GPS Navigation Systems
• Signal Level Translation
• Portable Gaming Consoles
• Media Players

Package and Quality

Encased in a compact QFN-14 package, the TXS0104ERGYR maximizes functionality in a minimal footprint, suitable for space-constrained applications. Texas Instruments' commitment to quality ensures that each device meets the highest standards of performance and reliability.
