Overview of Texas Instruments UCC28C44D

The UCC28C44D is a high-performance, BiCMOS off-line controller manufactured by Texas Instruments. This integrated circuit is specifically designed to provide efficient and reliable solutions for switch-mode power supplies. The device is suitable for a variety of applications, including offline flyback converters, forward converters, and boost converters used in consumer electronics, telecommunications, and industrial systems.

Key Features

• BiCMOS Technology: The UCC28C44D leverages BiCMOS technology, which combines the advantages of both Bipolar and CMOS transistors to achieve high speed and low power consumption.
• Programmable Switching Frequency: The device offers a programmable switching frequency ranging from 100 kHz to 1 MHz, allowing designers to optimize their power supply for efficiency or size.
• Current-Mode Control: With current-mode control, the UCC28C44D provides excellent output voltage regulation, fast transient response, and inherent protection against overcurrent conditions.
• Low Startup and Operating Current: The low startup current (typically 0.5 µA) and low operating current (typically 2.5 mA) minimize power losses and improve efficiency.
• Trimmed Oscillator Discharge Current: The oscillator discharge current is trimmed to ensure precise duty cycle clamping, which is crucial for the protection and stability of the power supply.

Protection Features

• Under-Voltage Lockout (UVLO): The UCC28C44D includes UVLO with hysteresis to ensure the controller starts up and shuts down at the correct voltage levels.
• Overcurrent Protection: The device features peak current limit protection to safeguard the power supply and load from excessive current.
• Automatic Restart: An onboard fault protection circuit triggers an auto-restart mode during fault conditions, enhancing the safety and reliability of the system.

Package and Availability

The Texas Instruments UCC28C44D is available in an 8-pin SOIC package, which is widely used and suitable for compact designs. The device is also characterized for operation from -40°C to 85°C, ensuring performance in a wide range of environmental conditions.

With its robust feature set and protection mechanisms, the UCC28C44D is an excellent choice for designers looking to create efficient, reliable, and compact power supply systems.
