ULN2003ADR

Part No ULN2003ADR
Manufacturer Texas Instruments
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC PWR RELAY 7NPN 1:1 16SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Switch Type Relay, Solenoid Driver
Number of Outputs 7
Output Type NPN
Voltage - Load 50V (Max)
Supply Voltage - Operating Not Required
Current - Output (Max) 500mA
Input Type Inverting
Temperature Range - Operating -20°C to 70°C (TA)
Case / Package 16-SOIC
Win Source Part Number 035956-ULN2003ADR
Family Name ULN2003AD
Introduction Date September 01, 2010
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Audio, Signal Processing, Industrial, Power Management
Ultra Librarian 3D Model Ultra Librarian ULN2003ADR CAD Model

Description

ULN2003ADR from Texas Instruments is a widely used load-driver device in the PMIC - Power Distribution Switches, Load Drivers category, commonly selected when low-power control logic must interface with higher-current loads. Engineers often use this part in relay driving, lamp control, solenoid actuation, motor interface stages, and general-purpose industrial or embedded control boards. Its value lies in simplifying output drive design, reducing the need for multiple discrete transistors, and helping compact controller-based systems manage external loads more efficiently. This makes it a practical choice for automation hardware, consumer appliances, instrumentation, and legacy-compatible control circuits. The current lifecycle status for ULN2003ADR is information not available in this review, so design teams should verify availability and long-term support directly with Texas Instruments or authorized distribution sources before committing to new production. RoHS compliance status is also information not available here and should be confirmed through official manufacturer documentation before use in regulated products.
