Overview of Texas Instruments XIO2213BZAY

The Texas Instruments XIO2213BZAY is a high-performance, PCIe to PCI translation bridge that is designed to enable users to connect legacy PCI devices to the newer, advanced PCIe slots on modern computers. This bridge is part of TI's extensive range of interface solutions and is particularly suited for applications that require a seamless integration of legacy hardware into new systems.

Key Features

• PCI Express to PCI Bridge: The XIO2213BZAY provides a single-lane (x1) PCI Express endpoint and an adaptable PCI/PCI-X host. Its design ensures a reliable connection between the two interfaces.
• High Performance: With its PCIe 1.1 compliance, the device offers a transfer rate of 2.5 Gbps per lane, ensuring high-speed data transfer between connected devices.
• Multiple Port Configurations: The bridge supports a 1394a-2000 OHCI PHY/link-layer controller that comes with three 1394 ports, offering flexibility in connecting multiple devices.
• Advanced Power Management: The XIO2213BZAY is equipped with power management features that comply with the PCI Power Management Interface Specification, which helps in reducing power consumption when the bridge is not in active use.

Applications

The XIO2213BZAY is ideal for a variety of applications, including:

• Industrial Control Systems
• Test and Measurement Devices
• Data Acquisition Systems
• Embedded Systems
• Legacy PCI Device Support

Technical Specifications

• Package: The device comes in a compact 144-pin LQFP (Low Profile Quad Flat Package) which is suitable for space-constrained applications.
• Temperature Range: It operates within an industrial temperature range, ensuring reliability and performance under varying environmental conditions.
• Support and Reliability: Backed by Texas Instruments' expertise and support, the XIO2213BZAY is a reliable solution for bridging PCIe and PCI interfaces.

With its robust feature set and dependable performance, the Texas Instruments XIO2213BZAY is an excellent choice for system designers and engineers looking to integrate or maintain PCI-based devices within modern computing environments.
