SSM3K341R,LF Toshiba Semiconductor and Storage SSM3K341R,LF real image11196 SSM3K341R,LF real image11197 SSM3K341R,LF Real Image1 SSM3K341R,LF Real Image2
Same model may have multiple batches, images only for reference.
SSM3K341R,LF Toshiba Semiconductor and Storage SSM3K341R,LF real image11196 SSM3K341R,LF real image11197 SSM3K341R,LF Real Image1 SSM3K341R,LF Real Image2
SSM3K341R,LF Toshiba Semiconductor and Storage SSM3K341R,LF real image11196 SSM3K341R,LF real image11197 SSM3K341R,LF Real Image1 SSM3K341R,LF Real Image2
Same model may have multiple batches, images only for reference.

SSM3K341R,LF

Part No SSM3K341R,LF
Manufacturer Toshiba Semiconductor and Storage
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 6A
Datasheet
SSM3K341R,LF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 6A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4V, 10V
Gate-Source Threshold Voltage 2.5V @ 100μA
Max Gate Charge 9.3nC @ 10V
Max Input Capacitance 550pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.2W (Ta)
Maximum Rds On at Id,Vgs 36 mOhm @ 5A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23F
Dimension SOT-23-3 Flat Leads
Win Source Part Number 1102303-SSM3K341R,LF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SSM3K341R,LF CAD Model

Description

The Toshiba Semiconductor and Storage MOSFET is a N-channel device with a drain-source breakdown voltage of 60V.

  • Category: Discrete Semiconductor Products
  • Maximum Power Dissipation: 1.2W
  • Temperature Range: -55°C to 175°C
  • Continuous Drain Current: 6A @ 25°C
  • Maximum Rds On @ Id, Vgs: 36 mOhm @ 5A, 10V
  • Gate-Source Threshold Voltage: 2.5V @ 100μA
  • Maximum Gate Charge: 9.3nC @ 10V
  • Maximum Input Capacitance: 550pF @ 10V
  • Mounting: SMD (SMT)
  • Package: SOT-23F
  • Supply and Demand Status: Balanced
