TLP293(GB-TPL,E

Name: TLP293(GB-TPL,E
Brand: Toshiba Semiconductor and Storage
SKU: 1316373
Availability: InStock
Rating: 4.85 (293 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP293(GB-TPL,E
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISOLATOR 3.75KV TRANS 4-SO / Optoisolator Transistor Output 3750Vrms 1 Channel 4-SO
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators>Optoisolators - Transistor, Photovoltaic Output
Mfr	Toshiba Semiconductor and Storage
Package	Tape & Reel
Number of Channels	1
Voltage - Isolation	3750Vrms
Current Transfer Ratio (Min)	100% @ 5mA
Current Transfer Ratio (Max)	600% @ 5mA
Turn On / Turn Off Time (Typ)	3µs, 3µs
Rise / Fall Time (Typ)	2µs, 3µs
Input Type	DC
Output Type	Transistor
Voltage - Output (Max)	80V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.25V
Current - DC Forward (If) (Max)	50 mA
Vce Saturation (Max)	300mV
Temperature Range - Operating	-55°C ~ 125°C
Mounting	SMD (SMT)
Package / Case	4-SOIC (0.179", 4.55mm Width)
Supplier Device Package	4-SO
Base Product Number	TLP293
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.49.8000
Win Source Part Number	1316373-TLP293(GB-TPL,E
Ultra Librarian 3D Model	Ultra Librarian TLP293(GB-TPL,E CAD Model
